Psb1080/1230 Full Thread Steel Bar

Short Description:


Product Detail

Parameter

Mechanical Properties

Product Tags

Psb1080/1230 Full Thread Steel Bar

PRESTRESSED THREAD BAR

In addition to confirming the structural integrity of the bridge, the post-tension rod system allows engineers to monitor the health and condition of the structure over time. By integrating sensors into the rebar, authorities can collect data on various parameters such as stress levels, temperature changes and vibration, allowing them to detect potential problems before they escalate into serious problems. This proactive approach to maintenance ensures the safety of bridge users and extends the life of the structure.

Grade PSB500,PSB830,PSB930,PSB1080
Diameter 15mm,0mm,25mm,32mm,36mm,40mm,50mm

Applications:

Our thread bar systems are used for connections, formwork and anchorages and have been installed in large-scale construction projects worldwide. Whether for building, underground, bridge or road construction, tunnelling or mining.

38 37

1742 44 45


  • Previous:
  • Next:

  • continuous threaded bar

    Nominal Diameter Diameter H B L Nominal Section Nominal Weight
    Dv Dh
    mm mm mm mm mm mm mm2 kg/m
    15 15 15 1.0 4.5 10 176 1.47
    18 18 18 1.0 4.0 10 254.5 2.11
    20 20 20 1.3 4.8 10 314 2.47
    25 25 25 1.6 6.0 12 490.9 4.10
    32 32 32 2.0 7.0 16 804.2 6.65
    36 36 36 2.5 8.0 18 1018 8.41
    40 40 40 3.0 8.0 20 1256.6 10.34
    50 50 50 3.0 9.0 24 1963.5 16.28
    60 60 60 3.0 10.0 22 2827 23.26
    63.5 63 63.5 3.0 12.0 22 3167 26.20
    65 65 65 3.0 12.0 22 3318 27.470
    70 70 70 3.0 12.0 22 3848 31.8
    75 75 75 3.0 12.0 22 4418 36.9
    Grade500/630 NominalDia. CrossSection YieldStrength TensileStrength YieldLoad UltimateLoad Elongation NominalWeight
    mm mm2 >=Mpa >=Mpa KN KN A/% KG/m
    20 314 500 630 157 198 10 2.47
    25 491 500 630 246 309 10 4.1
    28 615 500 630 308 387 10 4.83
