PriceList for Pt Bar And Nut - Steel Bar/All-Thread-Bar/Thread Bar/Fully Thread Bar/Screw Bar/Alloy Tension Bar – Cathay

Short Description:


Product Detail

Parameter

Mechanical Properties

Product Tags

Related Video

Feedback (2)

We persist with the principle of "quality 1st, assistance initially, continual improvement and innovation to meet the customers" for your management and "zero defect, zero complaints" as the standard objective. To great our service, we present the products and solutions while using the very good top quality at the reasonable cost for Macalloy Tie Bars , Copper Hex Nuts , Threaded Steel Bars 32mm , We have a big inventory to fulfill our customer's requires and needs.
PriceList for Pt Bar And Nut - Steel Bar/All-Thread-Bar/Thread Bar/Fully Thread Bar/Screw Bar/Alloy Tension Bar – Cathay Detail:

Steel Bar/All-Thread-Bar/Thread Bar/Fully Thread Bar/Screw Bar/Alloy Tension Bar

A post tension bar is a strong metal rod that is used in the construction of concrete structures such as bridges, buildings, and parking garages. Its advantage over traditional reinforcement is that it creates a compressive force within the concrete, which helps to counteract the tensile forces that the structure will experience over time. This can improve the strength, durability, and integrity of the concrete structure, making it more resistant to cracking, corrosion, and other forms of damage. Additionally, the use of post tension bars can help reduce the amount of material needed for a structure, making it lighter and more cost-effective.

Tianjin Guotai Qiancheng Iron & Steel Co., Ltd. specializes in the export of Screw thread steel bars for the prestressing of concrete and anchorages including HRB500, PSB500, PSB785,PSB830, PSB930, PSB1080 of 15mm, 16mm, 18mm 20mm, 22mm, 25mm, 28mm, 32mm, 36mm,40mm, 50mm, 75mm and other specifications, Left hand screw thread steel bars, Right hand screw thread steel bars and Deformed steel bars of HRB500E, HRB500 , HRB400E , HRB335 grades.

System Description:

The screw thread steel bars for the prestressing of concrete manufactured by our company is a high tensile alloy steel bar which features a coarse right-hand thread over its full length and available in two standard lengths, namely 9m and 12m,yet,special length is negotiable based on user’s demand subject to the maximum length of 18m.

The screw thread steel bar

Fully Threaded Bar - can be cut and coupled at any point.

Low Relaxation Steel - minimum relaxation during service life.

Prestressing Grade Steel - high strength offers weight savings and reduced working diameters.

Grade PSB500,PSB830,PSB930,PSB1080
Diameter 15mm,0mm,25mm,32mm,36mm,40mm,50mm

Applications:

Our thread bar systems are used for connections, formwork and anchorages and have been installed in large-scale construction projects worldwide. Whether for building, underground, bridge or road construction, tunnelling or mining.

Specification

rebar prices steel rebar PS500 screw-thread steel Hot rolled ribbed steel bar G500 standard

1. Different grade:  500/630, 830/1030, 930/1080, 1080/1230

2. Diameter range: 15mm, 20mm, 25mm, 32mm, 36mm, 40mm, 50mm, 63.5mm, 75mm

3. Usage: rock bolt, soil nailing, tunneling, mining, bridge construction

Stock with fastest dlievery

threadbar-1

39 12

38 37

17 444245

3

Contact Information

Wendy Lee

Tianjin Cathay Pacific Steel Co.,Ltd

Email: tjgtqc@tjgtqc.com

WhatsApp: 0086-176 1227 5091


Product detail pictures:

PriceList for Pt Bar And Nut -
 Steel Bar/All-Thread-Bar/Thread Bar/Fully Thread Bar/Screw Bar/Alloy Tension Bar – Cathay detail pictures

PriceList for Pt Bar And Nut -
 Steel Bar/All-Thread-Bar/Thread Bar/Fully Thread Bar/Screw Bar/Alloy Tension Bar – Cathay detail pictures

PriceList for Pt Bar And Nut -
 Steel Bar/All-Thread-Bar/Thread Bar/Fully Thread Bar/Screw Bar/Alloy Tension Bar – Cathay detail pictures

PriceList for Pt Bar And Nut -
 Steel Bar/All-Thread-Bar/Thread Bar/Fully Thread Bar/Screw Bar/Alloy Tension Bar – Cathay detail pictures

PriceList for Pt Bar And Nut -
 Steel Bar/All-Thread-Bar/Thread Bar/Fully Thread Bar/Screw Bar/Alloy Tension Bar – Cathay detail pictures

PriceList for Pt Bar And Nut -
 Steel Bar/All-Thread-Bar/Thread Bar/Fully Thread Bar/Screw Bar/Alloy Tension Bar – Cathay detail pictures


Related Product Guide:

We insist on the principle of development of 'High quality, Efficiency, Sincerity and Down-to-earth working approach' to deliver you with great provider of processing for PriceList for Pt Bar And Nut - Steel Bar/All-Thread-Bar/Thread Bar/Fully Thread Bar/Screw Bar/Alloy Tension Bar – Cathay, The product will supply to all over the world, such as: Japan , Mexico , Costa rica , When It produced, it making use of the world's major method for reliable operation, a low failure price, it appropriate for Jeddah shoppers choice. Our enterprise. s situated inside the national civilized cities, the website traffic is very hassle-free, unique geographical and financial circumstances. We pursue a "people-oriented, meticulous manufacturing, brainstorm, make brilliant" company philosophy. Strict good quality management, fantastic service, affordable cost in Jeddah is our stand around the premise of competitors. If needed, welcome to make contact with us by our web page or phone consultation, we will be delighted to serve you.

continuous threaded bar

Nominal Diameter Diameter H B L Nominal Section Nominal Weight
Dv Dh
mm mm mm mm mm mm mm2 kg/m
15 15 15 1.0 4.5 10 176 1.47
18 18 18 1.0 4.0 10 254.5 2.11
20 20 20 1.3 4.8 10 314 2.47
25 25 25 1.6 6.0 12 490.9 4.10
32 32 32 2.0 7.0 16 804.2 6.65
36 36 36 2.5 8.0 18 1018 8.41
40 40 40 3.0 8.0 20 1256.6 10.34
50 50 50 3.0 9.0 24 1963.5 16.28
60 60 60 3.0 10.0 22 2827 23.26
63.5 63 63.5 3.0 12.0 22 3167 26.20
65 65 65 3.0 12.0 22 3318 27.470
70 70 70 3.0 12.0 22 3848 31.8
75 75 75 3.0 12.0 22 4418 36.9
Grade500/630 NominalDia. CrossSection YieldStrength TensileStrength YieldLoad UltimateLoad Elongation NominalWeight
mm mm2 >=Mpa >=Mpa KN KN A/% KG/m
20 314 500 630 157 198 10 2.47
25 491 500 630 246 309 10 4.1
28 615 500 630 308 387 10 4.83
