High reputation Right Hand Thread Bar - Fully Soil Thread Bar – Cathay Detail:

Fully Soil Thread Bar

System Description:

The screw thread steel bars for the prestressing of concrete manufactured by our company is a high tensile alloy steel bar which features a coarse right-hand thread over its full length and available in two standard lengths, namely 9m and 12m,yet,special length is negotiable based on user’s demand subject to the maximum length of 18m.

The screw thread steel b

Fully Threaded Bar - can be cut and coupled at any point.

Low Relaxation Steel - minimum relaxation during service life.

Prestressing Grade Steel - high strength offers weight savings and reduced working diameters.

Grade PSB500,PSB830,PSB930,PSB1080
Diameter 15mm,0mm,25mm,32mm,36mm,40mm,50mm

Applications:

Our thread bar systems are used for connections, formwork and anchorages and have been installed in large-scale construction projects worldwide. Whether for building, underground, bridge or road construction, tunnelling or mining.



Specification

rebar prices steel rebar PS500 screw-thread steel Hot rolled ribbed steel bar G500 standard

1. Different grade:  500/630, 830/1030, 930/1080, 1080/1230

2. Diameter range: 15mm, 20mm, 25mm, 32mm, 36mm, 40mm, 50mm, 63.5mm, 75mm

3. Usage: rock bolt, soil nailing, tunneling, mining, bridge construction


Product Description


Production Flow


laboratory


Certifications


Company Information


Advantages


Packaging & Shipping



Stock with fastest dlievery

39 12

38 37

1742 44 45

20


Product detail pictures:

High reputation Right Hand Thread Bar - Fully Soil Thread Bar – Cathay detail pictures

High reputation Right Hand Thread Bar - Fully Soil Thread Bar – Cathay detail pictures

High reputation Right Hand Thread Bar - Fully Soil Thread Bar – Cathay detail pictures

High reputation Right Hand Thread Bar - Fully Soil Thread Bar – Cathay detail pictures

High reputation Right Hand Thread Bar - Fully Soil Thread Bar – Cathay detail pictures

High reputation Right Hand Thread Bar - Fully Soil Thread Bar – Cathay detail pictures

High reputation Right Hand Thread Bar - Fully Soil Thread Bar – Cathay detail pictures

High reputation Right Hand Thread Bar - Fully Soil Thread Bar – Cathay detail pictures


Related Product Guide:

Our commission should be to provide our end users and clients with very best excellent and aggressive portable digital products and solutions for High reputation Right Hand Thread Bar - Fully Soil Thread Bar – Cathay, The product will supply to all over the world, such as: Slovakia, Paraguay, Libya, The credibility is the priority, and the service is the vitality. We promise we have the ability to provide excellent quality and reasonable price products for customers. With us, your safety is guaranteed.

continuous threaded bar

Nominal Diameter Diameter H B L Nominal Section Nominal Weight
Dv Dh
mm mm mm mm mm mm mm2 kg/m
15 15 15 1.0 4.5 10 176 1.47
18 18 18 1.0 4.0 10 254.5 2.11
20 20 20 1.3 4.8 10 314 2.47
25 25 25 1.6 6.0 12 490.9 4.10
32 32 32 2.0 7.0 16 804.2 6.65
36 36 36 2.5 8.0 18 1018 8.41
40 40 40 3.0 8.0 20 1256.6 10.34
50 50 50 3.0 9.0 24 1963.5 16.28
60 60 60 3.0 10.0 22 2827 23.26
63.5 63 63.5 3.0 12.0 22 3167 26.20
65 65 65 3.0 12.0 22 3318 27.470
70 70 70 3.0 12.0 22 3848 31.8
75 75 75 3.0 12.0 22 4418 36.9
Grade500/630 NominalDia. CrossSection YieldStrength TensileStrength YieldLoad UltimateLoad Elongation NominalWeight
mm mm2 >=Mpa >=Mpa KN KN A/% KG/m
20 314 500 630 157 198 10 2.47
25 491 500 630 246 309 10 4.1
28 615 500 630 308 387 10 4.83
